Laser Line is Now Your Source for Canon Large Format Printers

Why out-source your large format projects?

Introducing the Canon imagePROGRAF PRO-4100S

Compare for yourself!Smarty McPage

Out-sourcing a 24×36 poster: $40-$50

Printed by you on your new Canon ImagePROGRAF Pro-4100S: $5.00

Specifications:

Printer Type

8-Color 44-inch Printer

Number of Nozzles

Total: 18,432
All colors: 1,536 nozzles

Nozzle Pitch

600 dpi x 2
Non-firing nozzle detection and compensation

Print Resolution (Up to)

2400×1200dpi (Max)

OS Compatibility

32bit: Windows® (7/8.1/10)
64bit: Windows 7, Windows 8.1, Windows 10Windows Server 2008R2, Windows Server 2012/2012R2Windows Server 2016, Windows Server 2019
Mac (OS 10.11.6), (Mac OS 10.12 – 10.15)

Standard Interfaces

USB 2.0 High-Speed
10/100/1000 Base-T/TX
Wireless LAN (IEEE 802.11 b/g/n)
USB Thumb Drive

Ink Droplet Size

minimum 4 picoliter

Ink Capacity

160, 330, or 700ml per color*

Ink Droplet Size

Pigment based LUCIA PRO Ink

Color Set

Photo Black, Matte Black, Cyan, Magenta, Yellow, Photo Cyan, Photo Magenta, Gray

Hard Drive

500GB

Media Width

Cut Sheet – 6- 44
Roll Feed – 6 – 44

Media Thickness

Roll: 0.07 – 0.8 mm (2.8 – 31.5mil)

Maximum Roll Print Length

Roll Feed – 59′ (18 meters)**

Maximum Media Roll Diameter

6.7 (170mm)

Borderless Printing Width

Custom roll width 6 – 44 with micro margin technology

Paper Feed Method

Roll Feed: One Roll, Front-loading, Front Output
Manual Feed: Front-loading, Front Output

Languages

Swift Graphic Raster (SGRaster)

Noise Level Approx

Operation: 49 dB (A) or less
Accoustic Power: 6.6 Bels or less

Physical Dimensions

46.0 (H) x 62.7 (W) x 38.7 (D) (with basket open)

Weight

approx.267 lbs (roll holder included, no inks, no print heads)

Power Source

AC 100-240V(50-60Hz)

Power Consumption

Maximum: 116 W or less
Standby 2 W or less
Power Off: 0.3 W or less

Operating Environment

Temperature: 59 – 86°F
Relative Humidity: 10-80% (No Condensation)

User-replaceable items

  • Print Head (PF-10)
  • Maintenance Cartridge (MC-30)
  • Ink Tanks (PFI-1100/PFI-1300/PFI-1700)

Software Included

Professional Print & Layout, imagePROGRAF Printer Driver, Quick Utility Toolbox, Accounting Manager, Device Management Console, Media Configuration Tool, PosterArtist Lite (PC only), Printer Driver Extra Kit (Free Layout and Advanced Preview), Direct Print & Share, Gallery Wrap Feature

Contact Laser Line today for more information!
